インテリジェント街路灯制御システム用車両モーションセンサー

道路/トンネル環境に応じて,、インテリジェント照明集中コントローラーと連携して、環境輝度の変化に応じてランプの照度を自動的に制御し,、インテリジェントな管理と制御の目的を達成します.。

According to the real time traffic flow rate conditions, it cooperates with the intelligent lighting centralized controller to automatically control the illuminance of the roadway lights according to the changing of city roads brightness, to achieve the purpose of intelligent public lighting management.

Key Features n Applicable to signal control systems, traffic information service systems, road traffic monitoring and other application scenarios. n High precision millimeter wave radar with 4 million low illumination camera. n Max. 8 lanes of multi-target motor vehicles detection, longitudinal distance of 100m. n High spatial resolution and strong penetration ability, support working in all-weather environment, not affected by rain, fog, strong wind, dust, light, etc. n Built-in deep learning algorithm, support intelligent recognition function, support license plate recognition and target fully structured. n Supports detection of multiple targets’ position, lane, speed, direction and other info. n It supports lane statistics, traffic flow, speed, status, queue, time distance, spacing, Qty.of parking areas, avg.delay, space occupancy and time occupancy data, and supports statistical upload from 1 to 3600 seconds. n Supports traffic evaluation data output, including congestion, queue length, etc. n Each lane supports 2 virtual coils to output vehicle entry and exit signals, the virtual coil positions are configurable. n Fog penetration, strong light suppression, wide dynamic range, and has multiple white balance modes to suit various scene requirements. n Support Network & RS-485 data upload. Parameters Millimeter Wave Radar Target Type People / Motor Vehicles / Non-Motor Vehicles Max. Qty. of Detection 128 Working Frequency 80 ~ 81GHz Transmit power 12dBm(RFout)+18dB(ANTgain) Speed Detect Range -250 km/h ~ 250 km/h Detection Mode Doppler moving target detection, slow moving target detection, fast moving target detection Sweep bandwidth 136.5 MHz Modulation Waveform FMCW Max. Detection Distance 150m@0° ;    50m@士45° Horizontal angle measurement range 士45° Horizontal lobe 90° for MRR, 22° for  LRR Vertical Lobe 13°(-6dB) Refresh rate 12.5Hz Install Height 1~ 6m   Interface Serial Port 1 of RS-485 Port Snapshot Function Image Format JPEG Image resolution 2688 × 1520 Smart Functions Intelligent recognition Bayonet capture, license plate recognition, vehicle model recognition, vehicle body color recognition, brand, sub-brand. Exterior Interface Ethernet 2pcs RJ45 100 M / 1000 M Adaptive Ethernet port  Warning 1 Relay switch Function Features Min.illumination Colorful: 0.01 Lux @ (F1.2，AGC ON) Black & White: 0.001 Lux @ (F1.2，AGC ON) shutter 1/25s ~ 1/100,000s Video compression standards H.264, H.265, MJPEG Compression output bit rate 32 Kbps ~ 16 Mbps Video resolution 2688 × 1520 Frame rate 25 fps (2688 × 1520) Image Settings Saturation, brightness, contrast, white balance, gain adjustable through software Storage function TF General functions Heartbeat, password protection, NTP time synchronization Video format PAL General Specifications Dimmensions 226 mm (W) x 375.3 mm (H) x 206.4 mm (D) Working Temperature -30 °C ~ +70 °C Working Humidity 5% ~ 95% @ 40 °C，No condensation Working Voltage DC 24 V ± 10% Power Consumption 25 W Max. N.W. 3 kg ICR Type Infrared IP Rating IP67 Focal Length 12 mm Resolution 2688 × 1520 White Balance Automatic white balance Wide dynamic range Support Max. Energy Optimization achieving by the Smart Traffic Radar  and Video all-in-one Detecting Machine

World-class industrial design and manufacturing capabilities enable us to produce top-quality xenon flash tubes in multiple shapes—including linear, U-shaped, spiral, and circular designs. Our tubes are engineered for a wide range of high-demand applications, including stroboscopic instruments, warning beacon lights, traffic-violation sensor cameras, professional photography, high-speed photography, graphic arts, airport runway lighting, solar simulation (providing high-intensity light that matches natural sunlight), air and water sterilization systems, IPL hair-removal devices, skin-treatment and freckle-removal equipment, medical devices, laser pumping, color-measurement systems, and high-precision laser-pulse xenon lamps for beauty applications. Our xenon flash tubes are also widely used in stage stroboscopic lighting and stroboscopic screens, police vehicle warning lights, emergency flashing beacons, signaling systems, speed-measurement equipment, timing systems, and many other industrial and safety applications. We proudly supply thousands of customers worldwide, including professional lighting manufacturers, research institutes and laboratories, universities, and global wholesalers and retailers. We provide a complete product series covering multiple shapes, dimensions, trigger-control types, and warning-beacon specifications—along with full supporting components such as trigger coils, transformers, capacitors, and necessary accessories.

Key Features: To prevent theft and vandalism, GPS positioning allows for real-time tracking of stolen street light. Hybrid AC & Solar Power or Pure Solar Power 4G Sim Card CAT 1 Communication Technology (Hybrid PLC / LoRa  /LoRaMesh) Auto-change Solar to AC by Smart Detect Sensor within 3 seconds Cloud based IoT Lighting Controlling & Monitoring Real Time Data: Watts / Voltage / Current / Power Factor can be Remote Reading Power Consumption / Faulty Reporting Using high efficiency 5050 leds,more than 200lm/w. Adopting high efficiency monocrystalline silicon solar panel, conversion rate is more than 21%. Grade A LiFePo4 battery,capacity is more than 80% after 2000 cycles. PWM and MPPT solar charger Horizontal or vertical pole installation,mounted angle is adjustable

世界クラスの工業用設計および最高品質のキセノンフラッシュチューブの製造：線形タイプ,U字型,スパイラル形状,ストロボスコープアプリケーション用の円形円形,警告灯,交通違反照明センサーカメラ,プロの写真,機械写真,空港の滑走路,空気と水源の滅菌と消毒,および脱毛機装置,美容装置とそばかす除去装置,医療装置,のIPL 3など.

スマート照明ターミナルコントローラーは、スマートシティの街路照明プロジェクト,高速道路トンネルや倉庫の産業用照明システム,工場,など. ,で広く使用されており、マンマシンを介して照明器具を制御します。インターフェイス,ランプの監視とデータ取得.

超高出力 200lm / w , 180lm / w , 160lm / w , 130lm / w さまざまな予算を満たすためのオプション. 高品質のLED街路灯 SOWINから,中国の大手LED街路灯メーカーからリーズナブルな価格でお問い合わせください.すべてがフィリップス,オスラムやクリー,などの世界的に有名なブランドリーダーのLEDチップとプロの道路照明光学レンズを採用しています高効率,および均一な光.の30Wから300W,の電力範囲で、あらゆる高さのポール,およびあらゆる種類の道路照明.に適しています。
